Our revolutionary Omnicut excavator rock saws are a world-first.

The Omnicut saws combine the hardness of diamonds with the robustness of tungsten carbide saws' construction to make a saw that can cut through hard and soft rock, reinforced concrete and wood, without the need to change the blade.

Download brochure

Product Range

Our extensive range allows us to tailor the rocksaw to suit the job and excavator

Single and multi-blade machines to fit excavators from 1 to 100 tonnes

Model	Optimum Excavator *Weight Range	**Blade Range Max.	Cutting Depth	Max. No ***Blades
	tonnes	mm	mm
tonnes	inches	inches
O1S	1 - 4	36 - 42	16	1
O2S	3 - 6	36 - 54	20	2
O3S	6 - 15	36 - 54	20	2
O3HP	6 - 15	42 - 59	24	2
O4HP	10 - 20	54 - 83	32	2
O5HP	16 - 30	60 - 98	39	3
O6HP	20 - 45	72 - 138	59	4
O7HP	40 - 90	98 - 156	70	7
O8HP	50 - 150	98 - 156	70	10

* based on average flow and pressure capabilities of a range of excavators

** maximum blade size for multiblade saws decreases with the number of blades

*** blade spacing to suit customer requirements tonnes mm mm

Accessories

• extension for cutting outside the tracks of the excavator with provision for additional head brackets
• additional head brackets to suit any excavator
• safety shield
• Cutting Optimiser for dramatic improvement of productivity

In most cases cooling water is not required. Cooling might be required in extremely tough materials.Water for dust suppression may be required.
