D4HS Diamond Rocksaw


For excavators 10 - 16 tonnes


Printer Friendly specification and recommended flow rates
Excavator RangeTonnes10 - 1612 - 20
Blade Diameter Range*mm400 - 800600 - 1400
Cutting Depth Loss*****mm150150
Continuous Pressure**MPa3842
Continuous Flowlpm350350
Output Power Continuous****kW230280
Spindle Speed Continuousrpm35002800
Spindle Torque ContinuousNM605836
Automatice Blade Brakeyesyes
Blade Rotation Reversibleyesyes
Case Drain Requiredyesyes

Notes to Specification

(*) other diameters can be also used, but performance will be notably sacrificed
(**) continuous - saw can be used continuously at this rating
(***) mass shown is for machine without blade
(****) Simultaneous application of maximum flow and pressure is not permissable, maximum power must be observed.
(*****) Calculate cutting depth = (Blade diameter/2)-Cutting depth loss

We are continually improving our products. Specification may change without notification. Check with your supplier for the latest specifications.
